The CXRF6160 X-ray fluorescence oil sulfur analyzer is mainly used to detect the sulfur content in oil products. It adopts the principle of energy dispersion and is environmentally friendly by itself. Its repeatability and reproducibility both comply with the relevant requirements of the national standards GB/T17040 and GB/T11140, and fully meet the requirements of the more stringent standard D4294-02. The price is only a fraction of that of imported instruments.

The main uses of the X-ray fluorescence oil sulfur analyzer：

• Measure the total sulfur mass percentage content of crude oil, petroleum, heavy oil, diesel, kerosene, gasoline and naphtha.
• Measure the total sulfur content in coal chemical products, such as primary benzene;
• Measurement of total sulfur content in other liquid samples;
• Determination of total sulfur content in fine powder samples;

Features of the fluorescence oil sulfur analyzer：

1. The instrument features an integrated mechanical and electrical microcomputer design, which is simple and elegant.
2. It features a wide range of detectable varieties, a broad detection range, fast analysis speed, and low consumption of standard samples.
3. The fluorescence intensity ratio relative comparison analysis method is adopted, with automatic correction for temperature and atmospheric pressure, and the carbon-hydrogen ratio (C/H) can also be corrected.
4. Large-screen LCD display, human-machine interaction for operation; In case of operational error, it can automatically sound an alarm.
5. The automatic diagnostic function of the instrument determines the working status and electrical parameters of the instrument through the counting measurement and energy spectrum measurement of the reference sample.
6. The instrument is equipped with a standard serial communication RS-232C interface, which can be connected to any computer or computer networking system.
7. Disposable single-sided Mylar film sample cups are adopted to avoid cross-contamination. The sample cup is made by using a multi-functional press, which is fast and convenient. The cup lid has air holes and can record the sample number, S%(m/m), and date.
8. The single sample stage is placed on the guide rail slider and can automatically enter and exit as instructed, with very accurate positioning. When waiting for sample analysis, it automatically extends outside the machine body, making it very convenient to place samples and replace oil-proof components.
9. The instrument has a large data storage capacity, and the content analysis results and calibration working curve parameters can be checked at any time.
10. Thermal printers are adopted, making it very convenient to change the printing paper and eliminating the need for printing ribbons as consumables.
11. Oil leakage is strictly protected. The sample cup is placed on the oil leakage prevention component and only enters the detection system together during sample analysis. During non-sample measurement periods, the oil leakage prevention component automatically moves outside the instrument to strictly protect the detection system from oil leakage contamination.
12. Safe X-ray protection measures: The detection system of the instrument is surrounded by strict protective measures to prevent X-ray leakage, ensuring no X-ray ionizing radiation harm to individuals or groups.

Technical specifications of fluorescent oil sulfur analyzer：

• Sulfur measurement range :7ppm to 5%;
• Repeatability (r): < 0.029(S+0.6);
• Reproducibility (R): < 0.063(S+0.6);
• Detection limit: 7ppm;
• Oil quantity :2 to 3ml(equivalent to an oil layer thickness of 3 to 4mm);
• Measurement time :60, 120, 240, 300, 600 seconds, freely set;
• Single sample automatic measurement, measurement times :2, 3, 5, 10, 50 times can be set arbitrarily. The average value and standard deviation are given at the end of the measurement.
• Number of calibration curves: The instrument can store and retrieve 9 calibration curves, among which 5 are linear lines with one variable and 4 are binomial parabolas.
• Working conditions: Temperature 5 to 40℃; Relative humidity: ≤ 85%(at 30℃)
• Power Supply :AC220V±20V,50Hz, rated power :30W;
• Dimensions and Weight :468mm×368mm×136mm; 13kg;
